BitLocker keys with out PIN safety, the place attackers may exploit stolen laptops, researchers now delve into PIN-secured setups, focusing on insider threats in search of SYSTEM-level entry.
This system entails intercepting TPM communications by way of SPI bus evaluation, revealing how even PIN-hardened BitLocker can yield to bodily probing with recognized credentials.
Whereas no true bypass happens, the tactic unlocks drives effectively, highlighting persistent {hardware} vulnerabilities in enterprise encryption.
Unraveling PIN-Protected BitLocker Mechanics
Not like TPM-only configurations that auto-unseal keys throughout boot, PIN-protected BitLocker layers further safeguards.
The Full Quantity Encryption Key (FVEK) stays on the disk, encrypted by the Quantity Grasp Key (VMK), however the VMK shifts to disk storage, protected by an Intermediate Key (IK).
This IK, in flip, is TPM-encrypted utilizing a Stretched Key (SK) derived from the consumer’s PIN, guaranteeing twin authentication: unsealing the IK and deriving decryption keys.
PIN Protected
This design thwarts brute-force assaults on-line by way of TPM lockouts, offline via randomized intermediates, however assumes safe {hardware} isolation.
Experiments by Guillaume Quéré on an HP ProBook 440 G1 revealed a discrete Nuvoton NPCT760HABYX TPM speaking over SPI, a shared bus simply tapped by way of close by MX25U reminiscence chip take a look at factors.
No soldering wanted; simply pins for clock, MOSI, and MISO strains, with CS non-obligatory for contemporary analyzers. Sign seize started pre-PIN entry utilizing a DSLogic Plus analyzer, however quirks emerged: the clock idled excessive at intermediate voltages, distorting readings.
A easy 4.7kΩ pulldown resistor grounded it, stabilizing the 33MHz SPI bus. But, TIS protocol anomalies continued double bytes per packet, possible from gradual acknowledgments, crippling automated decoders.
Guide decoding proved important. Filtering uncooked MOSI/MISO information with regexes stripped TIS wrappers (e.g., “00 D4 00 18 XX” for grasp requests), isolating TPM2.0 instructions by way of headers like “80 01” (plain) or “80 02” (authenticated).
Captures, beginning at PIN immediate, narrowed to key exchanges: ReadPublic for TPM keys, Load for objects, GetRandom for nonces, StartAuthSession, PolicyAuthValue/PCR for insurance policies, and crucially, Unseal for the IK blob.
Curiously, PINs by no means transmit to the TPM; they affect solely the Unseal HMAC, an undocumented nuance verified throughout good/dangerous PIN trials.
The Unseal response holds the encrypted IK, differing from non-PIN blobs attributable to PIN-derived SK. Deriving SK entails UTF-16LE PIN hashing, doubled SHA-256, then 1,048,576 rounds with disk salt compute-intensive however possible.
AES-CCM decryption with SK yields the IK, which unlocks the VMK from disk metadata by way of instruments like dislocker.
For the ProBook, Python code stretched the PIN “67851922” in opposition to salt “c36496f98842c6fd9841de2ea743d5cf”, decrypting the 44-byte IK payload.
Dislocker then mounted the amount read-write, enabling backdoors like overwriting sethc.exe with cmd.exe for Shift+5 privilege escalation.
Automated scripts, equivalent to SPITkey.py or tpm_sniffing_pin.py, streamline this, parsing volumes instantly or leveraging dislocker outputs.
This assault underscores discrete TPMs’ false safety; fTPM or PIN-plus-startup keys mitigate sniffing, although insiders stay dangers. Enterprises ought to audit configurations past defaults.
